RC Industries Underbody Tool Box M Series

RC Industries underbody truck tool boxes with drop down doors are available in steel, stainless steel or aluminum.

These tool boxes are designed to mount below the bed of a flatbed, service body truck, or trailer.

RC Industries Steel Underbody Tool Box Features:

• Choose from steel, steel with stainless steel door, stainless steel or aluminum.

• Steel Boxes come standard with 14 gauge steel and matte black finish.

• Aluminum boxes come standard with .125 inch Diamond plate aluminum.
• Pan formed drop down door with integrated gutter.
• Heavy duty door retainer chains.
• Stainless steel "L" style hinge.
• Automotive bulb seal for weatherproof seal.

• Optional: Add a gloss black or gloss white powder coat to any steel box.
• Optional: Add a gloss black or gloss white powder coat to any aluminum box.

RC Industries Steel Underbody Box Sizes & Dimensions:

Steel - Matte Black Finish / optional gloss black or gloss white finish

• 18"L x 12"D x 14"H: 54 pounds / single door
• 24"L x 12"D x 14"H: 56 pounds / single door
• 24"L x 16"D x 14"H: 60 pounds / single door
• 36"L x 16"D x 14"H: 84 pounds / single door
• 18"L x 18"D x 18"H: 60 pounds / single door
• 24"L x 18"D x 18"H: 72 pounds / single door
• 30"L x 18"D x 18"H: 88 pounds / single door
• 36"L x 18"D x 18"H: 96 pounds / single door
• 48"L x 18"D x 18"H: 122 pounds / single door
• 60"L x 18"D x 18"H: 140 pounds / single door
• 72"L x 18"D x 18"H: 158 pounds / double door
• 90"L x 18"D x 18"H: 186 pounds / double door
• 96"L x 18"D x 18"H: 196 pounds / double door
• 24"L x 24"D x 18"H: 90 pounds / single door
• 30"L x 24"D x 18"H: 107 pounds / single door
• 36"L x 24"D x 18"H: 123 pounds / single door
• 48"L x 24"D x 18"H: 155 pounds / single door
• 60"L x 24"D x 18"H: 188 pounds / single door
• 72"L x 24"D x 18"H: 224 pounds / double door
• 24"L x 24"D x 24"H: 109 pounds / single door
• 30"L x 24"D x 24"H: 130 pounds / single door
• 36"L x 24"D x 24"H: 140 pounds / single door
• 48"L x 24"D x 24"H: 185 pounds / single door
• 60"L x 24"D x 24"H: 222 pounds / single door
• 72"L x 24"D x 24"H: 242 pounds / double door
• 96"L x 24"D x 24"H: 280 pounds / double door

Aluminum: .125" Diamond Plate Finish / optional gloss black or gloss white finish

• 24"L x 16"D x 14"H: 34 pounds / single door
• 24"L x 18"D x 18"H: 38 pounds / single door
• 30"L x 18"D x 18"H: 46 pounds / single door
• 36"L x 18"D x 18"H: 58 pounds / single door
• 48"L x 18"D x 18"H: 68 pounds / single door
• 60"L x 18"D x 18"H: 82 pounds / single door
• 72"L x 18"D x 18"H: 96 pounds / double door
• 90"L x 18"D x 18"H: 113 pounds / double door
• 96"L x 18"D x 18"H: 130 pounds / double door
• 24"L x 24"D x 24"H: 53 pounds / single door
• 30"L x 24"D x 24"H: 62 pounds / single door
• 36"L x 24"D x 24"H: 70 pounds / single door
• 48"L x 24"D x 24"H: 84 pounds / single door
• 60"L x 24"D x 24"H: 100 pounds / single door
• 72"L x 24"D x 24"H: 114 pounds / double door
• 96"L x 24"D x 24"H: 155 pounds / double door

14 Gauge Steel  w/ Stainless Steel Door: Matte Black Finish / bright 14 gauge stainless steel door

• 24"L x 18"D x 18"H: 72 pounds / single door
• 30"L x 18"D x 18"H: 88 pounds / single door
• 36"L x 18"D x 18"H: 96 pounds / single door
• 48"L x 18"D x 18"H: 122 pounds / single door
• 60"L x 18"D x 18"H: 140 pounds / single door
• 72"L x 18"D x 18"H: 158 pounds / double door
• 90"L x 18"D x 18"H: 186 pounds / double door
• 96"L x 18"D x 18"H: 196 pounds / double door
• 24"L x 24"D x 18"H: 90 pounds / single door
• 24"L x 24"D x 24"H: 109 pounds / single door
• 30"L x 24"D x 24"H: 130 pounds / single door
• 36"L x 24"D x 24"H: 140 pounds / single door
• 48"L x 24"D x 24"H: 185 pounds / single door
• 60"L x 24"D x 24"H: 222 pounds / single door
• 72"L x 24"D x 24"H: 242 pounds / double door
• 96"L x 24"D x 24"H: 280 pounds / double door

Stainless Steel - 14 Gauge Bright Stainless Steel

• 24"L x 18"D x 18"H: 72 pounds / single door
• 30"L x 18"D x 18"H: 88 pounds / single door
• 36"L x 18"D x 18"H: 96 pounds / single door
• 48"L x 18"D x 18"H: 122 pounds / single door
• 60"L x 18"D x 18"H: 140 pounds / single door
• 72"L x 18"D x 18"H: 158 pounds / double door
• 90"L x 18"D x 18"H: 186 pounds / double door
• 96"L x 18"D x 18"H: 196 pounds / double door



Other Tool Box Options:

• For more options see other RC Industries Tool Boxes or all Underbody Tool Boxes.
